Dornbracht Lot Hot and Cold Water Dispenser

The award design Lot is sculptural in appearance. A superbly architectonic fitting with an ultra flat, one-piece spout. It is centred on its function, drawing itself back and that is precisely what makes it so evident. When combined with the choices of finish, its character oscillates between the sharpness of the form and the warmth of the material.

--

Lot allows you to set specific emphases in a minimalist ambience. Uncompromisingly pared down in form, yet still satisfyingly functional.

Finishes Available:  Polished Chrome, Platinum, Brushed Platinum , Brushed Durabrass, Brushed Dark Platinum

Set includes

Lot Hot and Cold Water Dispenser - 17 861 680

Hot water tank incl. filter - 12 893 97090

Product information

Projection - 145 mm

Height of mixer - 233 mm

Height up to laminar flow regulator - 213 mm

Hole diameter - 35 mm

Max flow - 2I/min at 3 bar flow pressure

Provides filtered, hot water up to 93°C

Provides filtered, cold water

Rigid, thermally insulated spout

Laminar flow

Ready to use control unit for wall mounting (135 x 160 mm x 60 mm)

Electronic magnetic valve

100-230 V, 50-60Hz. 18 W power supply unit, incl. country-specific adapter set

Lead-free

Additional information

A minimum flow pressure of 3 bar is necessary for the Hot and Cold Water Dispenser to work perfectly with a hot water tank and filter.

The filter cartridge must be changed every 6 months. The installation instructions contain further information and guidance.

For more information please contact a member of our design specialist for any requirements on 01423 863097.
